| ENGINE: | |
| Engine Type: | 4-Stroke, Single Cylinder |
| Displacement: | 49cc |
| Cooling: | Air Cooled |
| Max Horsepower: | 2.5hw/7000rpm |
| Max Torque: | 2.9N.m./6000rpm |
| Bore Stroke: | 1.54in x 1.63in |
| Max Speed: | 30 mph |
| Ignition: | CDI |
| Starting System: | Electric / Kick |
| Battery: | 12v/7Ah |
| Carburetor Type: | Automatic Choke |
| Engine Oil: | SAE 10W/30 |
| Gear Oil: | N/A |
| CHASSIS: | |
| Clutch: | Centrifugal, Wet Disc |
| Transmission: | Automatic |
| Drivetrain: | Belt-Drive |
| Driving Wheel(s): | Rear |
| Suspension Front: | Adjustable Front Forks |
| Suspension Rear: | Mono Shock |
| Brakes Front: | Hand Controlled Hydraulic Disc |
| Brakes Rear: | Hand Controlled Drum |
| Tires Front: | 3.50-10 |
| Tires Rear: | 3.50-10 |
| Fuel Capacity: | 1.6 gal |
| Fuel Type: | 91+ Premium |
| Weight: | 187 lbs |
| Max Load: | 220 lbs |
| DIMENSIONS: | |
| LxWxH(In): | 74″ x 27″ x 43″ |
| Height to Seat(In): | 30″ |
| Wheelbase(In): | 50″ |
| Ground Clearance(Inches): | 4.9″ |
